TNY278GN-TL,TinySwitch-III, Power Integrations, The TinySwitch-III family provides Low Power AC-DC Power Conversion (Up to 36.5 W)

700V Internal MOSFET Rating
Frequency Jitter Reduces EMI
EcoSmart® Low Standby/No-load Power Consumption
Latching Output Overvoltage Protection
Line Undervoltage (UV) Lockout
Selectable Current Limit

TNY278GN-TL ,TinySwitch-III incorporates a 700 V power MOSFET, oscillator, high voltage switched current source, current limit (user selectable) and thermal shutdown circuitry. The IC family uses an ON/OFF control scheme and offers a design flexible solution with a low system cost and extended power capability.

Simple ON/OFF control, no loop compensation needed
Selectable current limit through BP/M capacitor value
Maximizes MOSFET and magnetics power delivery
Minimizes max overload power
ON-time extension
Self-biased: no bias winding or bias components
Frequency jittering reduces EMI filter costs
Pin-out simplified es heatsinking to the PCB

TNY278GN-TL ,AC-DC Converters, Power Integrations

Part NumberTNY278GN
ManufacturerPower Integrations
DescriptionIC OFFLINE SWIT OVP OTP HV 8SMD
Lead Free Status / RoHS StatusLead free / RoHS Compliant
Data sheetTNY274-280
Voltage – Supply (Vcc/Vdd)
Voltage – Breakdown700V
TopologyFlyback
Supplier Device PackageSMD-8C
SeriesTinySwitch®-III
Power (Watts)28W
PackagingTube
Package / Case8-SMD (7 Leads), Gull Wing
Output IsolationIsolated
Other Names596-1577
TNY278GN-ND
Operating Temperature-40°C ~ 150°C (TJ)
Mounting TypeSurface Mount
Moisture Sensitivity Level (MSL)4 (72 Hours)
Lead Free Status / RoHS StatusLead free / RoHS Compliant
Internal Switch(s)Yes
Frequency – Switching132kHz
Fault ProtectionCurrent Limiting, Open Loop, Over Temperature, Over Voltage, Short Circuit
Duty Cycle65%
Detailed DescriptionConverter Offline Flyback Topology 132kHz SMD-8C
Control FeaturesEN
