SVI3206 – High-Efficiency Intelligent Power Module for Compact Inverter and Motor Control Applications
If you’re in need of a compact, integrated solution for motor drives or inverter circuits, the SVI3206 Intelligent Power Module (IPM) is a top-tier option. Developed by Sanken Electric, this module offers reliable high-speed switching, built-in protection features, and is ideal for 3-phase inverter circuits in a wide range of industrial applications.

⚙️ Product Overview: SVI3206
The SVI3206 is a high-performance 3-phase IPM that integrates six IGBT devices and their corresponding gate drive circuits in one compact, easy-to-install module. It simplifies system design and improves reliability by reducing external component count and offering robust protection against overcurrent and overtemperature.
🔧 Key Specifications:
- ✅ Topology: 3-phase inverter bridge
- ✅ IGBT Voltage Rating: 600V
- ✅ Current Rating: Approx. 15A–20A (varies by heatsink and application)
- ✅ Integrated Gate Drive & Protection Circuits
- ✅ Overcurrent, Overtemperature, and Undervoltage Protection
- ✅ Compact SIP (Single Inline Package) design
- ✅ Application-Friendly Pin Configuration
🏭 Ideal Applications
The SVI3206 module is designed for space-efficient, cost-effective, and high-reliability applications including:
- ⚙️ Inverter-Based Motor Controls
- 🌀 HVAC Systems
- 🏭 Industrial Fans & Pumps
- 🧰 Machine Tools
- 🔧 Small Servo Drives
- 🌬 Air Conditioner Compressor Controls
💡 Why Choose the SVI3206 IPM?
- 📦 Compact & Integrated: Combines IGBT switches and driver logic in a small footprint
- 🔧 Design Simplification: Reduces engineering effort and board space
- ⚡ Efficient Switching: Minimizes power loss in high-speed motor control
- 🛡 Built-In Protections: Avoids damage from overcurrent, overtemp, and undervoltage events
- ✅ Reliable Brand: Made by Sanken, a leader in industrial power semiconductors
🔎 SEO Keywords for Better Visibility
- “SVI3206 IPM module for sale”
- “Buy SVI3206 online”
- “Sanken SVI3206 datasheet”
- “SVI3206 intelligent power module”
- “SVI3206 3-phase inverter module”
- “600V IGBT power module”
- “SVI3206 motor drive IPM”
🛒 Buy SVI3206 – Fast Delivery, Bulk Discounts Available
We offer authentic Sanken SVI3206 modules with competitive pricing, fast global shipping, and technical support. Whether you’re designing new equipment or replacing components in an existing system, the SVI3206 delivers performance and reliability.
📞 Contact us today for a quote, to check availability, or to download the SVI3206 datasheet.
